3D Design and Coordination:

Laser Scanning and BIM

Astra Engineering captures existing conditions with laser scanning and ground penetrating radar, then models industrial plants in 3D from existing conditions through construction documents. Every discipline works in the same live Revit models through Autodesk Forma, so engineers, contractors, and equipment vendors see changes as they happen, and conflicts are resolved in design instead of in the field. We model new plants and expansions as well as the existing facilities that new work has to fit into.

What We Do:

  • Terrestrial laser scanning

  • Ground penetrating radar

  • Scan to BIM

  • Revit and Plant 3D modeling

  • BIM execution and clash detection

  • Construction documents and as built models

Astra Engineering 3D point cloud model of an industrial facility layout with machinery and equipment.

Laser Scanning

We laser scan plants, buildings, and equipment to capture existing conditions before design starts. Scans are registered and processed in Autodesk ReCap and brought directly into our Revit models, so new equipment, piping, and steel are designed to what is actually there.

What you get

  • Terrestrial laser scans of buildings, equipment, and piping

  • Registered point clouds in Autodesk ReCap

  • Scans of areas with missing or outdated drawings

  • Progress scans to compare construction with the design

Diagram illustrating ground-penetrating radar (GPR) with an antenna on the surface detecting a buried object, showing two-way travel time and signal trace.

Ground Penetrating Radar

We use ground penetrating radar to locate buried utilities and structures before excavation, and to scan concrete before cutting or coring. Results are marked in the field and brought into the site and building models so crews dig and core with fewer surprises.

What you get

  • Buried utility and structure locating before excavation

  • Concrete scanning for rebar, conduit, and voids before cutting or coring

  • Field marking of located features

  • Results brought into the civil and building models

Laser scan point cloud of a ball mill building at an operating concentrator

Scan to BIM

We turn point clouds into accurate Revit models of the structures, equipment, and piping that new work has to fit around. The model is built to the level of detail the project needs, from building outlines to individual pipe supports.

What you get

  • Revit models of existing structures, equipment, and piping

  • Model detail matched to the needs of the project

  • Existing conditions drawings from the model

  • Field verification of critical dimensions

Revit and Plant 3D Modeling

We model buildings, steel, equipment, piping, and electrical in the same environment, built to our own Revit standards and detail library. On new plants the model starts at concept layout, and on expansions it is built into the scan of the existing facility.

What you get

  • Building, structural, and equipment models

  • Process piping models in Revit and Plant 3D

  • Electrical and cable tray models

  • Models built to Astra Engineering Revit standards

3D model of HVAC ductwork system

BIM Execution and Clash Detection

At the start of a project, we write the BIM execution plan that defines model ownership, level of detail, file exchange, and the review schedule for every party. We run clash detection in Navisworks at each milestone and bring vendor equipment models into the plant model, shared through Autodesk Forma.

What you get

  • BIM execution plans

  • Model management and version control

  • Clash detection in Navisworks at each milestone

  • Vendor and contractor model coordination through Autodesk Forma

3D model of process tanks, piping, and platforms designed by Astra Engineering

Construction Documents and As Built Models

We deliver drawings, spool sheets, and specifications at the detail the project needs, from LOD 100 to LOD 500. At closeout you receive the native model files, updated to as built conditions, to keep for future work.

What you get

  • Construction drawings and specifications from the model

  • Spool sheets for piping fabrication

  • Model reviews documented in Bluebeam Revu

  • As built models and native files at closeout

What You Can Expect

Each project starts with a BIM execution plan, plus a laser scan or GPR survey where existing conditions matter. We hold model reviews with your team and contractors at set milestones and document them in Bluebeam Revu. We deliver construction documents and a final model you keep.

3D model of a granulator process line with steel platforms and stairs designed by Astra Engineering

Project Types:

New process plants and expansions

Equipment installations in operating facilities

Piping and utility reroutes

Semiconductor and advanced technology facilities

Close-up of a technical drawing with precise measurements, a wooden pencil pointing at the drawing, and a metal ruler edged in white.
